L.O.A............................37'0"
L.W.L............................31'7"
Beam............................11'5"
Freeboard, stem...............4'7"
Freeboard, stern..............3'7"
Displacement.........17,000lbs.
Ballast*....................6,600lbs.
Sail Area..................667sq.ft.
Mast height......................54'
Draft................................5'9"
(Shoal draft 4'9")
Sail Area/Displacement...16.1
Displacement/Length........239
Ballast/Displacement.........39
Beam/Length Ratio............31
*External Lead
|
|
